Chapter 3: Functional Description
Interfaces & Signals
Table 3–7. System Signals (Part 2 of 2)
3–29
Signal Name
write_clk
dqs_ref_clk
fedback_clock_out
stratix_dll_control
Direction
Input
Output
Output
Output
Description
Shifted clock that center aligns write data to the memory.
Stratix DLL reference clock output.
Fed-back clock output.
Disables the Stratix DLL reference clock during reads.
Note to Table 3–7 :
(1) This signal only exists on the custom variation when a dedicated clock phase is required, otherwise the connection is made inside the custom
variation.
Figure 3–19. Circuit for resynch_clk_edge_select
Capture
Register
Resynchronization
Register
Extra
Resynchronization
M u ltiplex
Pipeline
Register
local_rdata
Register
Table 3–8 shows the DDR and DDR2 SDRAM controller local interface signals.
Table 3–8. Local Interface Signals (Part 1 of 2)
Signal Name
local_addr[]
local_be[]
local_burstbegin
local_read_req
local_refresh_req
Direction
Input
Input
Input
Input
Input
Description
Memory address at which the burst should start. The width of this bus is sized
using the following equation:
For one chip select:
width = bank bits + row bits + column bits – 1
For multiple chip selects:
width = chip bits + bank bits + row bits + column bits – 1
The least significant bit (LSB) of the column address on the memory side is
ignored, because the local data width is twice that of the memory data bus
width.
The order of the address bits is set in the clear text part of the MegaCore
function ( auk_ddr_sdram.vhd ). The order is chips, bank, row, column, but
you can change it if required.
Byte enable signal, which you use to mask off individual bytes during writes.
Avalon-MM burst begin strobe, which indicates the beginning of an Avalon-
MM burst. This signal is only available when the local interface is an Avalon-
MM interface and the memory burst length is greater than 2.
Read request signal.
User controlled refresh request. If User Controlled Refresh is turned on,
local_refresh_req becomes available and you are responsible for
issuing sufficient refresh requests to meet the memory requirements. This
option allows complete control over when refreshes are issued to the memory
including ganging together multiple refresh commands. Refresh requests take
priority over read and write requests unless they are already being processed.
? March 2009
Altera Corporation
DDR and DDR2 SDRAM Controller Compiler User Guide
